Cast Steel Slab Gate Valve for Oil & Gas Pipelines
API 6D cast steel slab gate valve available in full-bore and reduced-bore configurations for oil and gas transmission pipelines. The full-bore version supports online pigging where required by the pipeline design.
| Size Range | 2″–60″ (DN50–DN1500) |
|---|---|
| Pressure Rating | Class 150–300 (PN16–PN50) |
| Body Material | Carbon steel, alloy steel, stainless steel, duplex steel, etc. |
| Connection Type | RF, BW, RTJ, etc. |
| Operation | Manual, pneumatic, electric, hydraulic actuation, etc. |
| Applicable Standard | API 6D |
| Flow Configuration | Full bore or reduced bore |
Frequently Asked Questions
Review the service medium, pipeline flow requirement, required bore configuration, end connection, actuation method and project specification. If online pigging is required, confirm the full-bore configuration during technical review.
Yes, the original product information states that the full-bore version supports online pigging. The selected bore, internal passage and pipeline pigging requirements should be confirmed during technical review.
This model is listed for oil and gas transmission pipelines. Final suitability depends on the service medium, pressure, connection, selected body material and the project specification.
Listed options include manual, pneumatic, electric and hydraulic actuation. The appropriate method should be selected against valve size, operating frequency, available utilities and the control requirement.
Provide the required bore configuration, service medium, size, pressure class, body material, end connection, actuation method, quantity and applicable project documentation for engineering review.
Product Overview
The Vornet Cast Steel Slab Gate Valve is designed for isolation duty in oil and gas transmission pipelines. Its slab gate configuration is available with either a full-bore or reduced-bore flow path, allowing the valve arrangement to be matched to pipeline operating and engineering requirements.
During operation, the slab gate moves linearly between the seats to open or isolate the flow passage. For projects that require pipeline pigging, the published full-bore version provides the required continuous passage, while the reduced-bore option can be considered when permitted by the pipeline specification.
The product can be configured with the listed carbon steel, alloy steel, stainless steel or duplex steel body materials, RF/BW/RTJ end connections and manual, pneumatic, electric or hydraulic actuation. Each selection should be reviewed against the stated API 6D design basis and actual service conditions.
- Pipeline Isolation: Designed for oil and gas transmission pipeline applications.
- Bore Selection: Full-bore and reduced-bore configurations support different engineering requirements.
- Online Pigging: The full-bore version supports online pigging as stated in the original product information.
- Configuration Options: Listed materials, end connections and operating methods support project-specific selection.
