Forged Steel Slab Gate Valve for High-Pressure Pipelines
API 6D forged steel slab gate valve for high-pressure oil and gas pipelines, combining forged body strength with reliable sealing performance for large-size pipeline isolation.
| Valve Type | Forged Steel Slab Gate Valve | Pressure Rating | Class 150~2500(PN16~PN420) |
|---|---|---|---|
| Size Range | 3″–24″ (DN80–DN600) | Body Materials | Carbon steel, alloy steel, stainless steel, duplex steel, etc. |
| Connection Type | RF, BW, RTJ, etc. | Operation | Manual, gear, electric, etc. |
| Applicable Standard | API 6D | ||
Frequently Asked Questions
It is designed for isolation service in high-pressure oil and gas pipelines, particularly where the listed 3″–24″ range and forged body construction match the project requirements.
The original product description identifies the forged steel body as providing high-pressure resistance, while the valve design is intended to deliver reliable sealing performance in high-pressure pipeline service.
The connection should be selected to match the pipeline design and project specification. RF, BW and RTJ are the connection options identified on this product page.
API 6D is the applicable standard stated in the original product description. Additional purchaser or project requirements should be identified during technical review.
Buyers should provide the required size, pressure class, body material, connection type, operating method and pipeline service so the listed options can be checked against the project specification.
Product Overview
This forged steel slab gate valve is engineered for on-off isolation in high-pressure oil and gas pipeline systems. The slab gate travels between the seating surfaces to open or shut the flow path, providing a direct isolation function across the listed 3″–24″ size range.
Its forged steel body is designed to provide the high-pressure resistance identified in the original product description. Combined with the valve’s sealing design, this construction supports reliable shutoff performance for demanding transmission pipeline applications.
Engineering teams can select from the listed carbon steel, alloy steel, stainless steel and duplex steel materials, together with RF, BW or RTJ connections and manual, gear or electric operation. This range of configurations helps align the valve with pipeline layout, pressure class and project requirements under API 6D.
- High-Pressure Pipeline Isolation: Intended for oil and gas transmission applications requiring dependable on-off service.
- Forged Steel Construction: Provides the pressure resistance stated in the original product information.
- Reliable Sealing Performance: Supports shutoff requirements in demanding pipeline conditions.
- Engineering Flexibility: Multiple listed materials, end connections and operating methods support project-specific selection.
